钢丝铠装船用电缆
CHEPJP80/SC, CHEPFP80/SC船用电缆技术
CHEPJP80/SC, CHEPFP80/SC船用电缆技术
对数x3x截面积 No of triples x 3 x cross section area | CHEPJP80/SC, CHEPFP80/SC船用电缆技术 | CHEPJP90/SC, CHEPFP90/SC | CHEPJP85/SC, CHEPFP86/SC CHEPJP95/SC, CHEPFP96/SC | ||||||||
外径 Overall diameter | 约重 Approx . weight | 外径 Overall diameter | 大约重量 Approx. weight | 外径 Overall diameter | 大约重量 Approx. weight | ||||||
标称 Nom. | 很大 Max. | 标称 Nom. | 很大 Max. | 80系列 | 90系列 | 标称 Nom. | 很大 Max. | 85系列 | 95系列 | ||
No.x 3 x mm2 | kg/km | kg/km | kg/km | kg/km | kg/km | ||||||
1x3 x 1.5 2x3 x 1.5 3x3 x 1.5 4x3 x 1.5 5x3 x 1.5 7x3 x 1.5 10x3 x 1.5 12x3 x 1.5 14x3 x 1.5 16x3 x 1.5 19x3 x 1.5 24x3 x 1.5 27x3 x 1.5 30x3 x 1.5 33x3 x 1.5 37x3 x 1.5 43x3 x 1.5 48x3 x 1.5 | 9.6 16.6 17.6 19.6 21.5 23.7 31.1 32.2 34.1 36.3 38.5 45.7 46.9 48.7 50.8 53.1 58.0 61.5 | 11.0 18.5 19.5 22.0 24.0 26.0 34.0 35.5 37.5 39.5 42.0 50.0 51.0 53.5 55.5 58.0 63.5 67.0 | 118 248 324 415 498 662 968 1116 1285 1460 1705 2166 2406 2635 2888 3215 3741 4160 | 10.7 18.2 19.2 21.2 23.1 25.3 33.2 34.3 36.2 38.4 40.6 47.8 49 50.8 52.9 55.2 60.1 63.6 | 12.0 20.0 21.0 23.5 25.5 27.5 36.0 37.5 39.5 42.0 44.0 52.0 53.5 55.5 58.0 55.0 65.5 69.0 | 178 399 487 599 701 891 1360 1527 1725 1933 2214 2775 3040 3300 3588 3956 4561 5039 | 171 382 469 579 679 867 1318 1483 1679 1883 2161 2713 2977 3234 3519 3885 4483 4956 | 12.8 20.7 21.7 23.7 25.8 28 36.3 37.6 39.5 41.9 44.1 51.7 52.9 54.9 57 59.5 64.6 68.3 | 14.0 22.5 24.0 26.0 28.5 30.5 39.5 41.0 43.0 45.5 48.0 56.0 57.0 59.5 62.0 64.5 70.0 74.0 | 226 494 583 702 823 1018 1551 1736 1940 2173 2460 3102 3365 3654 3950 4350 5006 5529 | 219 476 565 681 801 994 1508 1692 1893 2124 2407 3040 3302 3588 3881 4278 4927 5447 |
